NASA Frame number F225B69

Viking 2 image of the region around the "Inca City". Viking 2 also imaged the region, but no evidence of the feature was visible in this image from orbit 225. It has been enhanced to bring out the details (noise reduced and contrast enhanced). The resolution of the original image is 0.544 km/pixel and is centered at -81.56 degrees latitude and 69.82 degrees longitude. Reproduced from volume 55 of the Mission to Mars: Viking Orbiter Images of Mars CD-ROM set.

NASA Frame number F421B64

Viking 2 image of the region around the "Inca City". On a later orbit (421), Viking 2 again imaged the region. This time, the Inca City is clearly visible. This image was taken through the red filter. It has been enhanced to bring out the details (noise reduced and contrast enhanced). The resolution of this image is 0.146 km/pixel and is centered at -81.82 degrees latitude and 59.59 degrees longitude. Reproduced from volume 59 of the Mission to Mars: Viking Orbiter Images of Mars CD-ROM set.

 (A) Portion of Viking Orbiter 2 image 421B64, reproduced here (click on icon) at full resolution of about 179 meters (585 feet) per picture element. The outlines of (B) is shown. North is up, sun illumination is from the top.


(B) Highest-resolution pre-Mars Global Surveyor view. Image is a portion of Mariner 9 DAS #8044333. Click on the small view above to see the image at full spatial resolution of approximately 100 meters (327 feet) per pixel. White box indicates location of MOC image (C). North is approximately "up", sun illumination is from top/upper right.

(C) Subframe of MOC image 7908 reproduced at full resolution, about 23 meters/pixel (75 feet/pixel). Picture shows an area approximately 20 x 14 km (12.4 x 8.7 miles) in size. Sun illumination is from upper left.

This set of rectilinear, intersecting ridges was first seen in images taken by Mariner 9 in 1972 (see context frame B). The superficial resemblance to ancient ruins led to their informal name, "Inca City". As 1997 turned to 1998, MOC obtained this stunning high-resolution view during the 79th orbit of Mars Global Surveyor. The subframe depicted here is centered on 81.54°S latitude, 64.28°W longitude.

Except for the small dark dots, everything in this image is covered by a moderately thin (probably less than a meter) layer of seasonal, CO2 frost.

CREDIT: Malin Space Systems/NASA Paper
